Fiber optik dağıtım modülü orjinal ürün. Commscope Amp TE Tyco Raychem
Product Classification
| Regional Availability |
Asia | Australia/New Zealand | EMEA | Latin America | North America |
| Portfolio |
CommScope® |
| Product Type |
Fiber module |
| Product Series |
G2 |
General Specifications
| Color, front |
Aqua |
| Color, rear |
Gray |
| Interface, front |
LC |
| Interface Feature, front |
Standard |
| Interface, rear |
MPO Pinned |
| Interface Feature, rear |
Key up/up |
| Polarity |
Method B |
| Shuttered |
Yes |
| Total Fibers, quantity |
24 |
Dimensions
| Height |
25.51 mm | 1.004 in |
| Width |
95.91 mm | 3.776 in |
| Depth |
119.69 mm | 4.712 in |
Optical Specifications
| Fiber Mode |
Multimode |
| Fiber Type |
OM4 |
| Insertion Loss, maximum |
0.47 dB |
Environmental Specifications
| Qualification Standards |
IEC 61753-1 | TIA-568.3-D |
| Safety Standard |
CE | CSA | UL |
Packaging and Weights
| Packaging quantity |
1 |
| Weight, net |
0.109 kg | 0.240 lb |
